testo 380 Fine Dust Measurement System with testo 300 SE

The leakage test device DP5 is used to inspect exhaust systems at 200, 1,500, and 5,000 Pa (classes P1, M1, H1). Another application is to verify sufficient combustion air supply according to TRGI.Testing Procedures:Simplified Procedure: Measurement during the operation of a gas applianceDetailed Procedure: Measurement with defined air extraction using the DP5You can watch an application video here.Advantages:Battery operation enables measurements from the roofMains operation for uninterrupted workNow also testing exhaust pipes with 5,000 PaLightweight and handyHigher utility by testing air yield according to TRGIEasy operation via a very large 7" touch screenTechnical Data:Pressure Measurement Range 1: 0 to 5,000 PaPressure Measurement Range 2: 0 to 125 PaAir Volume Flow: 0 to 60 m³/hBattery: 24V with 3.2AhMains Operation: 230 VWeight: approx. 3.8 kgDimensions: 22x31x8.5 cm (WxHxD)LCD Color Touch Display: 7"USB and IRDA InterfaceTÜV CertifiedDelivery Contents:Leakage Test Device DP5Integrated BatterySealing Bladder with Device Hose NW 50-150 mmSealing Bladder with Valve NW 50-150 mmProtective Bag4/8 Pa Hose SetSealing ElementMains/ChargerThis comprehensive and user-friendly device ensures accurate and efficient testing of exhaust systems, making it an essential tool for professionals in the field.

The newly developed digital HD chimney inspection camera SK7 delivers razor-sharp images in HD quality.The power supply is provided by advanced lithium-ion battery technology, ensuring long operating time.The inspection camera is a compact and user-friendly device, ideal for inspections from the roof. Its large 7" color monitor displays sharp images. Photos and videos can be easily stored on an SD card and played back on-site. The display also shows time and date, and the digital meter counter simplifies length measurement.A sunshield makes inspections easier even in bright daylight. It is magnetically attached around the carrying handle and serves as display protection during transport.On the back, there is a protected storage compartment for the camera head. Additionally, the SK7 can be connected to a camera reel.The package includes a carrying harness, ensuring optimal handling on the roof—keeping both hands free at all times!The HD rotating ball camera is controlled via a joystick. It has an infinite rotation range and a 90° tilt range. The camera module is protected behind a glass cover and surrounded by a bright SMD lighting ring with a reflector for optimal illumination.The camera module automatically adjusts the focus, requiring no manual adjustments during inspections.The new HD camera module generates high-resolution images.A reel connection (optional accessory) can be easily attached via a bayonet lock, enabling inspections from bottom to top as well.Technical Data – SK7 HD:Digital meter count displayed on the LCDVoltage indicator (unit: %) displayed on the LCDPhoto & video storage on SD cardRotatable cable reel with 20 m cableCable connection: 8-pin connector7" color LCD TFT displayResolution: 1280 x 720 pixelsLithium-ion batteryBattery runtime: approx. 4 hoursCharging time: approx. 3.5 hoursDimensions: 307 x 285 x 200 mm (W x H x D)Weight: approx. 4.31 kgTechnical Data – HD Rotating Ball Camera:Camera module resolution: 1280 x 720 pixelsColor CCD camera moduleLight sensitivity: 0.8 LuxTilt range: 90°Rotation range: Endless (no stop)Bright lighting with 15 SMDsConnector: 8-pin plugHead diameter: 56 mm, Length: 152 mmWeight: approx. 326 gScope of Delivery:HD Chimney Inspection Camera SK7HD Rotating Ball Camera4 GB SD card20 m cableSunshieldCarrying harnessPower supply unit

The newly developed HD color monitor, with its compact size and lightweight design, is the perfect companion for a measuring case or backpack. The integrated lithium-ion battery ensures an operating time of approximately 2.5 hours. Photos and videos can be stored on the SD card.The battery level is displayed on the LCD screen.The new HD pan-and-tilt camera is controlled using four control buttons. It has a rotation range of 360° and a tilt range of 90°. The camera module is protected behind a glass panel and surrounded by a lighting ring with a reflector, ensuring optimal illumination.The HD-MK29 is designed for use in exhaust ducts. The flexible hydraulic hose provides excellent bendability. The camera module is safely enclosed behind a glass panel, surrounded by a reflector with built-in lighting for very bright illumination. The ultra-bright LED lighting and the 135° super wide-angle lens enable an excellent all-around view.Technical Data – 5" HD Monitor:Image and video storage on SD cardHD display 5"LED voltage display in percentage on displayAluminum cover plateDimensions: 135 x 220 x 39 mm (W x H x D)Weight: approx. 1100gTechnical Data – HD Pan-and-Tilt Camera:High-precision camera lens (92°) with automatic aperture controlHD camera module8-pin connectorLight sensitivity: 0.8 LuxBright illumination with 15 SMDsHead diameter: 55 mm, length: 153 mmWeight: approx. 312 gTechnical Data – HD Miniature Camera MK29:HD camera moduleLight sensitivity: 0.3 LuxDiameter: 29 mmHead length: 68 mmTotal length: 190 mmIllumination: 15 SMDsWeight: approx. 110 gField of view: 135°Technical Data – HD Cable Reel:Digital meter counter8-pin connector on the handle and 12-pin connector at the rod endCan be used as a handheld or coupling reelFiberglass camera rod: 20 m length, Ø 4.5 mmTransport lockFreewheel brake via needle bearingDimensions: 31 x 31 x 13.5 cm (W x H x D)Weight: 1.75 kgBasket diameter: 31 cmScope of Delivery:HD color monitor FM5 ProHD pan-and-tilt cameraHD miniature camera MK29HD mini cable reel20 m metered cable2 m connection cableProtective pouch with magnetPower adapterSD card

The gas leak detector "GasPen digital" is applicable for locating gas leaks on indoor and outdoor areas. With the movable sensor head you can also measure in unapproachable locations. The gas sensor fitted in the sensor head, reacts to Methane (CH4, natural gas). The measuring range starts with 100 ppm up to 10.000 ppm (1,0 Vol%). The results can be heard through an acoustic signal or/and 5 LEDs, which are assigned to particular gas concentration. - Dimension: 25 x 45 x 136 mm - Flexible piece 160 mm - Weight: 145 g (incl. Battery) - Operating time: 12 hours - Battery LED Delivery contents GasPen light, plastic case, 2 x 1,5 V Battery, control certificate, manual
